PROSOFT MVI94-MCM I/O平臺錯誤句柄PROSOFT MVI94-MCM I/O平臺錯誤句柄指定觸發器進入和退出錯誤狀態時要執行的可選傳輸列表。觸發錯誤狀態將由任何包含的標簽訪問或傳輸失敗啟動。成功完成觸發器后，將清除“錯誤狀態”。指定的錯誤句柄傳輸列表也可以使用單獨的周期觸發器執行，以在需要/需要時刷新數據。傳輸列表將包含一個或多個消息命令。列表中的每個命令都將指定完成一個數據傳輸事務所需的所有信息，其方式與RA梯形圖邏輯中的MSG指令包含一條消息的所有信息非常相似。PROSOFT MVI94-MCM I/O平臺可以創建多個傳輸列表，通過將相關消息分組在一起，幫助您更好地組織通信任務。這也允許通過稱為觸發器或觸發器事件的數據標記值的更改來控制消息組。
PROSOFT MVI94-MCM I/O平臺可以通過背板直接將數據傳輸?shù)桨惭b在同一機箱中的ControlLogix PAC，也可以從安裝在該機箱中的Control Logix PAC傳輸數據。這種跨ControlLogix背板通信的能力意味著PROSOFT MVI94-MCM I/O平臺還可以利用某些RA通信模塊和協議的“橋接”能力。6.1.2觸發器觸發器允許您通過鏈接到一個邏輯事件或一個或多個受監控標記的值的更改來控制PROSOFT MVI94-MCM I/O平臺中的消息執行。觸發器可以鏈接到一個或多個傳輸列表。當觸發條件為true時，關聯的一個或多個傳輸列表將執行配置的數據傳輸命令。PROSOFT MVI94-MCM I/O平臺觸發器允許最終用戶對消息執行進行一定程度的邏輯控制。如果使用現有流程變量標記或現有條件標記作為觸發標記，則正常流程執行將觸發消息傳輸，而不需要額外的控制邏輯。有兩種類型的觸發器，PROSOFT MVI94-MCM I/O平臺包括ILX34_Trig和MM_Stats。這兩種類型都包括Actions和Error Handle，如下屏幕所示。操作指定觸發器觸發時要執行的可選傳輸列表。
PROSOFT MVI94-MCM I/O平臺Each command in the list will specify all the information needed to complete one data transfer transaction,MVI94-MCM, in much the same way as a MSG instruction in RA ladder logic would contain all the information for one message. Multiple Transfer Lists may be created to help you better organize your communications tasks by allowing related messages to be grouped together. This also allows groups of messages to be controlled by changes of data tag values, called Triggers or trigger events.
Error Handle ILX56-MM Error Handle specifies an optional Transfer List to execute when the Trigger enters and exits the Error State. The Trigger Error State will be initiated by any contained Tag Access or transfer failure. The Error State will be cleared on a successful trigger completion. The specified Error Handle Transfer List can also be executed with a separate PeriodicMVI94-MCM, Trigger to refresh the data if desired/required.A Transfer List will contain one or more message commands.
Triggers Triggers allow you to control message execution in the ILX56-MM by linking to a logical event or the change of value of a monitored tag or tags. A Trigger may be linked to one or more Transfer Lists. When the trigger conditions are true, the associated Transfer List or Lists will execute the configured data transfer commands.Triggers allows end-users a measure of logic control over message execution. If existing process variable tags or existing conditional tags are used as trigger tags, normal process execution will trigger message transfers with no additional control logic needed.MVI94-MCM, There are two types of triggers consisting of ILX34_Trig, and MM_Stats. Both types include Actions and Error Handle as seen in the following screen.Actions specify an optional Transfer List to execute when the Trigger is fired.
