PROSOFT MVI56-MBP 變頻器
MVI56-MBP提供三個安全級別：· GUEST：不需要用戶登錄帳戶?！?項目：您必須以具有項目權限的用戶身份登錄· 管理員。您必須以具有管理員權限的用戶身份登錄。下表介紹了需要安全權限的功能。位置功能權限要求狀態欄設置模式項目配置編輯器所有功能項目管理所有功能管理員管理/用戶沒有管理員權限就無法查看此頁面當您收到新模塊時，它會配置一個具有管理員權限（完全訪問所有模塊功能）的默認用戶。用戶名：admin密碼：admin配置您的用戶和管理員帳戶后，您應該刪除默認的“MVI56-MBP”用戶以獲得額外的安全性。如果您忘記了用戶名和/或密碼，您可以重置管理員設置跳線（MVI56-MBP）。如果您已刪除默認管理員用戶，則默認管理員用戶將恢復為具有管理員權限。掃描儀模式掃描儀模式控制觸發器的掃描（MVI56-MBP）和設備之間的數據傳輸。掃描儀可以處于以下模式之一：· 在STOP（停止）模式下，觸發器不被掃描，并且沒有任何接口處于活動狀態。只有當發生嚴重錯誤時，掃描儀才會進入“停止”模式。您不能自己將掃描儀置于“停止”模式。
MVI56-MBP模塊可以從互聯網上的SNTP時間服務器或與MVI56-MBP位于同一機架中的ControlLogix處理器獲取時間信號。MVI56-MBP還可以在定義為設備的ControlLogix、CompactLogix和FlexLogix處理器上設置時間。字段描述時區選擇模塊的時區。源模塊可以輪詢一個或多個源以獲取時間信號。時間源指定時間同步的IP地址。模塊將嘗試按指定的順序與這些源中的每一個同步，直到成功為止。MVI56-MBP是模塊等待從每個源接收時間信號的秒數。目的地選擇將與模塊上的時間同步的其他設備。此列表中的項目源自您在配置編輯器中定義的設備。頻率指定模塊接收和發送時間同步的頻率。當模塊切換到運行時，將啟動時間同步周期。單擊“保存”按鈕將時間設置保存到模塊中。手動時間設置設置時間和日期，然后單擊設置手動時間按鈕。要將模塊上的時間和日期與本地計算機上的時間同步，請單擊“同步當前時間”按鈕。審核日志是自模塊首次啟動以來發生的操作系統事件的按時間順序排列的日志。審核日志每頁顯示50條記錄，順序是從最新的頂部到最舊的底部。審核日志記錄以下類型的事件：· 更改模塊的操作模式· 修改配置· 更改事件日志級別· 重新初始化模塊· 備份配置· 正在恢復配置· 更新模塊· 其他不太頻繁的系統事件操作說明下一步50單擊Next 50按鈕查看當前50個事件開始顯示之前發生的50個事件。前50單擊前50按鈕查看當前50個事件開始顯示后發生的50個事件。
Reinitializing the module · Backing up the configuration · Restoring the configuration · Updating the module · Other less frequent system events Operation Description Next 50 Click the NEXT 50 button to view the 50 events that occurred prior to the current 50 events begin displayed. Previous 50 Click the PREVIOUS 50 button to view the 50 events that occurred after the current 50 events begin displayed.The MVI56-MBP provides three levels of security: · GUEST: No user login account is required. · PROJECT: You must be logged in as a user with Project privilege · MVI56-MBP. You must be logged in as a user with Administrator privilege.The following table describes functions that require security privilege. Location Function Privilege Required Status Bar Set Mode Project Configuration Editor All Functions Project Administration All Functions Administrator Administration/Users This page cannot be viewed without Administrator privilege When you receive a new module, it comes configured with one default user who has Administrator privileges (full access to all module functions).MVI56-MBP
Frequency Specify how often the module will receive and send time synchronization.MVI56-MBP A Time Sync cycle will be started when the module is switched to Run. Click the SAVE button to save your Time settings to the module. Manual Time Set Set the time and date, and then click the SET MVI56-MBPTIME button. To synchronize the time and date on the module to the time and date on your local computer, click the SYNC CURRENT TIME button.The audit log is a chronological log of operational system events that have occurred since the module was first started. The audit log displays 50 records per page, in order from newest, at the top, to oldest, at the bottom. The Audit Log records the following types of events: · Changing the module's operational mode ·MVI56-MBP Modifying the configuration · Changing the event log level
The MVI56-MBP module can acquire a time signal from an SNTP time server on the Internet, or from the ControlLogix processor in the same rack with the MVI56-MBP. The MVI56-MBP can also set the time on ControlLogix, CompactLogix, and FlexLogix processors defined as Devices.Field Description Timezone Select the time zone for the module. Source The module can poll one or more sources for a time signal. MVI56-MBP specify the IP addresses for the time synchronization. The module will attempt to synchronize with each of these sources in the specified order until it is successful. MVI56-MBP is the number of seconds the module will wait to receive the time signal from each source. Destination Select other devices that will be synchronized to the time on the module. The items on this list are derived from the devices you have defined in the Configuration Editor.
