PROSOFT MVI56E-MNETXT 可編程控制器
警告：MVI56E-SIE當背板電源打開時插入或卸下模塊時，可能會發生電弧。電弧可能會因以下原因造成人身傷害或財產損失：? 向系統的執行器發送錯誤信號，導致機器意外運動或失去過程控制? 在危險環境中引發爆炸。繼續操作前，請確認電源已斷開或該區域無危險。反復的電弧會導致模塊及其配對連接器上的觸點過度磨損。觸點磨損可能會產生電阻，從而影響模塊的工作。1將模塊與頂部和底部導軌對齊，然后將其滑入機架，直到模塊牢固地靠在背板連接器上。MVI56E-SIE 2用力但穩定地推動，將模塊卡入到位。3檢查模塊頂部和底部的固定夾是否牢固地位于機架的鎖定孔中MVI56E-SIE。4打開電源。注意：如果模塊插入不當，系統可能會停止工作，或者可能出現不可預測的行為。
MVI56E-SIE
如果您尚未安裝和配置MVI56E-SIE處理器和電源，請?jiān)诎惭bMVI56E-SIE模塊之前進行安裝和配置。有關安裝說明，請參閱羅克韋爾自動化產品文檔。警告：安裝此或任何其他電子設備時，必須遵守所有安全說明。不遵守安全程序可能導致硬件或數據損壞，甚至人員重傷或死亡。在安裝或維修設備之前，請參閱計劃連接的每個設備的文檔，以驗證是否有適當?shù)陌踩绦颉?/span>檢查跳線的位置后，將MVI56E-SIE插入ControlLogix機箱。使用羅克韋爾自動化推薦的相同技術來拆卸和安裝MVI56E-SIE模塊。您可以在機箱通電和系統運行時安裝或卸下MVI56E-SIE系統組件。但是，請注意以下警告。
Worn contacts may create electrical resistance that can affect module operation. 1 Align the module with the top and bottom guides, and then slide it into the rack until the module is firmly against the backplane connector. 2 With a firm but steady push, snap the module into place. 3 Check that the holding clips on the top and bottom of the module are securely in the locking holes of the rack. MVI56E-SIE 4 Turn power ON. Note: If you insert the module improperly, the system may stop working, or may behave unpredictably.
Use the same technique recommended by Rockwell Automation to remove and install ControlLogix modules. You can install or remove ControlLogix system components while chassis power is applied and the system is operating. However,MVI56E-SIE please note the following warning. Warning: When you insert or remove the module while backplane power is on, an electrical arc can occur. An electrical arc can cause personal injury or property damage by: § sending an erroneous signal to your system's actuators causing unintended machine motion or loss of process control § causing an explosion in a hazardous environment Verify that power is removed or the area is non-hazardous before proceeding. Repeated electrical arcing causes excessive wear to contacts on both the module and its mating connector.
If you have not already installed and configured your ControlLogix processor and power supply, please do so before installing the ILX56-MM module. Refer to your Rockwell Automation product documentation for installation instructions. Warning: You must follow all safety instructions when installing this or any other electronic devices. Failure to follow safety procedures could result in damage to hardware or data, or even serious injury or death to personnel.MVI56E-SIE Refer to the documentation for each device you plan to connect to verify that suitable safety procedures are in place before installing or servicing the device. After you have checked the placement of the jumper,MVI56E-SIE insert ILX56-MM into the ControlLogix chassis.
