測試臺工具工具說明應用程序測試臺，Woodward P/N 205975驅動調速器，提供壓力下的油，并包含用于監測調速器運行的儀表。電子計數器和頻率傳感器用于指示調速器驅動速度。在1秒的時間基礎上，每轉輸出必須至少為60赫茲。必須指示驅動速度在±1 rpm以內。顯示時間的讀數不得超過5秒。壓力表（0至200 psi/0至1400 kPa）檢查調速器油壓。發動機上的測試程序這些調整和測試程序根據調速器是否有下垂部件來劃分。遵循適用的說明。無下垂部件的UG杠桿試驗（參考圖6-1）1。拆下針閥塞（146）端部相對側調速器底座上的管塞（9），連接一個0–200 psi（0–1400 kPa）的壓力表。2.將調速器安裝在試驗臺上或發動機墊上。參見第2章。3.給調速器加油。參見第2章，供油。油位必須達到油視鏡上的標記。4.將補償調整指針設置在指針刻度的中點。
除了正常的連桿連接外，還將鋸齒扳手連接到轉速設定軸上，以便用鋸齒扳手手動控制發動機轉速。然后向調速器加油（請參閱第2章“供油”）。油位必須達到油視鏡上的標記。關閉針閥，將其重新打開1/2至3/4圈（參見第4章，補償調整），并將補償調整指針設置在中點。如果要進行準確的測試和調整，最好使用測試臺，因?yàn)楫?dāng)調速器安裝在發動機上時很難進行測試和調整。聯系Woodward獲取每個調速器名稱的測試規范副本。表4-1中列出的工具是可選的，除非大量調速器正在維修，否則不是絕對必要的。但是，總是需要使用壓力表來檢查工作油壓。啟動發動機、渦輪機或其他類型的原動機時，要做好緊急停機的準備，以防止失控或超速，從而可能造成人身傷害、生命損失或財產損失。按照原動機制造商的說明啟動原動機。表4-1。
Test Procedures on the Engine These adjustments and test procedures are divided by whether the governor has droop parts or does not. Follow whichever instructions are applicable. UG Lever Test without Droop Parts (Reference Figure 6-1) 1. Remove pipe plug (9) in the base of the governor on the opposite side of the needle valve plug (146) end attach a 0–200 psi (0–1400 kPa) pressure gauge. 2. Install the governor on a test stand or on the engine pad. See Chapter 2. 3. Fill the governor with oil. See Chapter 2, Oil Supply. The oil level must be to the mark on the oil sight glass. 4. Set the compensation adjusting pointer at mid-point on the pointer scale.
Be prepared to make an emergency shutdown when starting the engine, turbine, or other type of prime mover, to protect against runaway or overspeed with possible personal injury, loss of life, or property damage. Follow prime mover manufacturer’s instructions to start the prime mover. Table 4-1. Test Stand Tools Tool Description Application Test stand, Woodward P/N 205975 Drives governor, supplies oil under pressure and contains gauges for monitoring governor operation. Electronic Counter & Frequency Pickup To indicate governor drive speed. Must have an output of at least 60 Hz per revolution on a onesecond time base. Must indicate drive speed to within ±1 rpm. Readouts of display time must not exceed 5 seconds. Pressure Gauge (0 to 200 psi/0 to 1400 kPa) Check governor oil pressure.
Attach a serration wrench to the speed setting shaft in addition to the normal linkage attachment to manually control engine speed with the serration wrench. Then fill the governor with oil (see Chapter 2, Oil Supply). The oil level must be to the mark on the oil sight glass. Close the needle valve and reopen it 1/2 to 3/4 turns (see Chapter 4, Compensation Adjustments) and set the compensation adjusting pointer at mid-point. If accurate tests and adjustments are to be made, it is best to use a test stand since it is difficult to make them when the governor is mounted on an engine. Contact Woodward for a copy of the test specification for each governor designation. The tools listed in Table 4-1 are optional and not absolutely necessary unless a large number of governors is being repaired. The pressure gauge, however, is always needed to check operating oil pressure.
