允許動力活塞下的機油流向油底殼。動力油缸頂部的油壓迫使動力活塞下降到零燃油位置。如果正確調整了與發動機的連桿，發動機將關閉。5304-MBP-PDPM，以更好地了解UG杠桿調速器的操作。本原理圖為基本設計，不包括任何輔助設備。本說明基于負荷變化引起的速度變化。但是，如果通過重新定位速度控制連桿來更改調速器速度設置，則會發生相同的調速器移動順序。負載降低假設原動機以一定速度運行。5304-MBP-PDPM飛錘處于垂直位置，用于正常穩態操作。先導閥柱塞（14）的控制平臺位于旋轉襯套（15）的控制端口的中心。這會阻止壓力油流過襯套（15）控制端口。因此，動力活塞（7）和調速器輸出軸（6）都不會移動。
如果轉速下降小于50 rpm，調速器顯示下降小于3.5%。當調速器輸出軸（5）移動以增加燃油時，轉速設定值彈簧壓縮減小，從而降低調速器轉速設定值。當施加負載時，機組開始減速。當調速器輸出軸（5）移動以減少燃油時，轉速設定彈簧壓縮增加，從而增加調速器轉速設定。隨著負載的降低，機組開始提高速度。當負載增加或減少時，調速器速度設置的這種變化有助于調速器在機組與其他機組機械連接時抵抗負載變化。速降組件（圖3-2）由速降桿組件、速降凸輪和速降連桿組件組成，設置后，當調速器輸出軸旋轉時，速降連桿會改變速度設定彈簧的壓縮。有關可選降速組件的圖示零件和零件參考號，請參見圖6-1.如果希望從節氣門位置關閉發動機，5304-MBP-PDPM杠桿調速器可以配備一個停機桿（5304-MBP-PDPM），操作如下：當節氣門朝著停機位置移動時，加速塞上升，接觸停機桿上的螺母。進一步移動會提升停機桿、提升調速器桿和浮動桿的內端，從而提升先導閥柱塞并打開先導閥襯套中的控制端口。
If the linkage to engine is correctly adjusted, the engine will shut down.efer to Figure 3-1 with the text to better understand the operation of the UG Lever governor. This schematic diagram is of a basic design and does not include any auxiliary equipment. This description is based on speed changes resulting from load changes. However, the same sequence of governor movements would occur if the governor speed setting were changed by repositioning the speed control linkage. Decrease in Load Assume the prime mover is running on-speed. The flyweights are in a vertical position for normal steady-state operation. The control land of the pilot valve plunger (14) is centered over the control port of the rotating bushing (5304-MBP-PDPM). This stops the flow of pressure oil through the bushing (15) control port. As a result, there is no movement of the power piston (7) and no movement of the governor output shaft (6).
The speed droop assembly (Figure 3-2) consists of a speed droop lever assembly, a speed droop cam, and a speed droop link assembly which, when set, changes the compression of the speed setting spring as the governor output shaft rotates. For illustrated parts and part reference numbers of the optional speed droop assembly, see Figure 6-1.If it is desired that the engine be shut down from the throttle position, the UG Lever governor can be equipped with a shutdown rod (Figure 3-3) operating as follows: When the throttle is moved toward the shutdown position, the speeder plug rises, contacting the nut on the shutdown rod. Further movement lifts the shutdown rod, lifting speeder rod and inner end of floating lever, thus raising the pilot valve plunger and uncovering the control port in the pilot valve bushing. This permits oil under the power piston to flow to sump. Oil pressure on top of the power cylinder forces the power piston down to the zero fuel position.
lf the decrease in speed is less than 50 rpm, droop less than 3.5% is shown by the governor. As the governor output shaft (5) moves to increase fuel, the speed setting spring compression is reduced, which reduces the governor speed setting. The unit starts reducing its speed as load is applied. When the governor output shaft (5) moves to decrease fuel, the speed setting spring compression is increased, which increases the governor speed setting. The unit starts increasing its speed as load is decreased. This change of governor speed setting when load is increased or decreased helps the governor resist a load change when the unit is connected mechanically with other units.
