810-800082-009增加手動設定位置設置，直到致動器定位在最大停止位置，或者用手將輸出推入最大停止位置。10.將At Max Position（在最大位置）參數設置為true，以允許控制記錄最大位置設置。11.當Min和Max都已成功校準時，將Enable Manual Stroke（啟用手動沖程）設置回false（如果啟用了手動校準）。如果成功，Calibration Status（校準狀態）將指示校準已完成。如果校準不成功，狀態將指示“失敗”。810-800082-009驗證校準。這可以手動完成，方法是將機架從最小值移動到最大值，觀察位置讀數（維修工具或模擬輸出），或?qū)⑹謩訂⒂迷O(shè)置為真，并使用手動設置位置變量定位輸出。13.調整動態。調整執行器慣性設置以獲得正確的系統性能。810-800082-009增加設置意味著系統中的慣性更高，并導致致動器中的增益更高。使用執行器慣性測試執行命令驗證設置。關于基于操縱桿尺寸的近似慣性設置，請參閱表9-1。14.可選地，在每個停止處設置所需的偏移（偏置）?！坝布{(diào)整”中提供了“最小停止偏移”和“最大停止偏移”參數，基本上可以在用戶校準的停止設置內提供電氣停止。該偏移以行程的度數為單位，可以隨時調整。810-800082-009：硬件調整。
要進入用戶校準模式，必須關閉設備并輸入密碼。有關用戶校準的概述，請參閱所附的流程圖（圖9-7和9-8）。調整制動器和動態系統的步驟1。810-800082-009使用RS-232零調制解調器電纜將PC連接到ProAct。2.在電腦上運行Servlink并連接到ProAct控件。請參閱維修工具一章，了解入門部分中有關Servlink設置和連接的詳細信息。3.打開電腦上的“監視窗口”或其他編程工具。4。通過PC發出關閉命令（在機組狀態選項卡頁上）或打開ProAct低功率待機模式離散輸入來關閉ProAct。任何一種方法都會使機組處于停機狀態，這是對調整用戶停機模式的許可。5.810-800082-009從服務：調整用戶停止選項卡工作表中輸入調整用戶停止密碼（模式密碼）。ProAct將提供反饋，表明用戶已通過操作模式和模式啟用指示成功進入停止校準模式。6。選擇所需的校準模式。有兩種模式，手動沖程模式和自動模式。參見圖9-7和圖9-8。如果選擇了自動模式，步驟7至11將自動執行，無需任何用戶輸入。通過將“自動執行”設置為true，810-800082-009可啟用自動模式。7.有兩種方法可以手動在最小和最大位置之間移動輸出：手動或使用手動設置位置。要使用手動設置位置，必須將手動啟用設置為true。使用手動設置位置定位ProAct，降低需求設置，直到致動器定位在最小停止位置，或者用手將輸出推入最小停止位置。8.將At Min Position（在最小位置）參數設置為true，810-800082-009以允許Control記錄最小位置設置。
Verify Calibration. This can be done by hand by moving the rack from min to max and observing the position readout (Service Tool or analog out) or by stetting the Manual Enable to true and positioning the output using the Manual Set Position variable. 810-800082-009 Adjust Dynamics. Adjust the Actuator Inertia Setting for proper system performance. Increasing the setting implies a higher inertia in the system and results in a higher gain in the actuator. Verify the setting with the Actuator Inertia 810-800082-009Test Execute command. Refer to Table 9-1 for an approximate inertia setting based on lever size. 14. Optionally, set the offset (bias) desired at each stop. The Min Stop Bias and Max Stop Bias parameters are available in the Hardware Adjustments to basically provide an electrical stop within the user calibrated stop settings810-800082-009.810-800082-009 This offset is in degrees of travel and can be adjusted anytime. Refer to Figure 9-5 and Service Mode: Hardware adjustments later in this chapter.
There are two methods to manually move the output between min and max position: by hand or by using the Manual Set Position. To use the Manual Set Position, the Manual enable must be set to true. Using the Manual Set Position to position the ProAct, decrease the demand setting until the actuator is positioned at the minimum stop or, by hand, push the output into the min stop.810-800082-009 Set the At Min Position parameter to true to allow the Control to record the Min position setting. 810-800082-009 Increase the Manual Set Position setting until the actuator is positioned at the maximum stop or, by hand, push the output into the max stop. 10. Set the At Max Position parameter to true to allow the Control to record the Max position setting. 810-800082-009. When both Min and Max have been successfully calibrated, set the Enable Manual Stroke back to false (if a Manual Calibration is enabled). If successful, the Calibration Status will indicate the calibration is complete. The status will indicate ‘failed’ if the calibration is unsuccessful.
To enter the User Calibration mode, the unit must be shut down and a password must be entered. For an overview of the User Calibration, refer to the attached flowcharts (Figures 9-7 and 9-8). Procedure to Adjust Stops and Dynamics 810-800082-009. Connect PC to ProAct using an RS-232 Null Modem cable. 810-800082-009 Run Servlink on the PC and connect to the ProAct control. Refer to the Service Tool chapter for details on Servlink setting and connection in the Getting Started section. 3. Open Watch Window or alternative programming tool on the PC. 4. Shut down the ProAct by either issuing a Shutdown Command from the PC (on the Unit Status tab sheet) or by opening the ProAct Low Power Standby Mode Discrete Input. Either method puts the unit in a shutdown state, which is a permissive for the Adjust User Stops mode. 810-800082-009. Enter the Adjust User Stops Password (Mode Password) from the Service: Adjust User Stops tab sheet. The ProAct will provide feedback that the user stops calibration mode has been successfully entered through the Operational Mode and Mode Enabled indications.6. Select the desired calibration mode. There are 2 modes, a manual stroking mode and an automatic mode. Refer to Figures 9-7 and 9-8. If the Auto mode is selected, steps 7 through 11 will occur automatically without any user input required. Auto Mode is enabled by setting “Auto Execute” to true.
