LAM 810-017038-002 PCB擴展卡
產品概述：
810-017038-002 （%）-持續更新的Can位置需求信號指示，即使在出現故障時，也以用戶校準范圍的百分比表示。810-017038-002 （%）-即使出現故障，PWM輸入位置需求信號的持續更新指示，以用戶校準范圍的百分比表示。Xfer to Backup當設置為true時，此用戶命令強制將需求信號從主信號轉換為配置的備份信號。810-017038-002 如果備份請求失敗或“Xfer to Primary”命令為true，則不執行強制。用于測試主/備份傳輸，并方便添加子板命令所需的代碼。Xfer to Primary User命令將控制從備份轉移到配置的主信號（如果未失?。?。通常情況下，如果主服務器正在正確跟蹤，則會自動執行此操作。此命令強制傳輸?shù)街鞣?wù)器，即使它可能未在服務模式中設置的容差范圍內跟蹤備份。此命令通過將需求傳輸?shù)街骺丶ⅰ癤fer to Backup”設置為false來覆蓋“Xfer to Backup”命令。810-017038-002 服務：狀態錯誤警報狀態錯誤警報選項卡頁包含所有受監控致動器警報的狀態信息。值為TRUE時，表示報警狀態處于激活狀態。報警指示為非閉鎖狀態，當條件不再存在時返回false。有關詳細信息，請參閱第6章中的報警診斷。
此指示不包括跟蹤錯誤。810-017038-002 如果存在需求跟蹤錯誤，則職位需求不會從備份轉移到主位置。備份控制–如果備份需求是選定的需求信號，則控制指示為true。如果主信號出現故障，裝置將保持備用控制，并在信號恢復且在跟蹤誤差范圍內（請參閱維修：硬件調整）時傳輸回主信號。810-017038-002 備用需求信號狀態的備用故障指示。True失敗，否則為false。此指示不包括跟蹤錯誤。需求–模擬需求（%）-即使失敗，810-017038-002 模擬輸入位置需求信號的持續更新指示，以用戶校準范圍的百分比表示。
The position demand will not transfer from the backup to the primary if a demand tracking error exists. Backup Control–Control Indication—true if the backup demand is the selected demand signal.810-017038-002 Unit will remain in backup control if the primary signal fails and transfers back to primary when the signal is restored and within the tracking error (see Service: Hardware Adjustments).810-017038-002 Backup Fault—Indication of the backup demand signal status. True is failed and false if not. This indication does not include a tracking error.810-017038-002 Demand–Analog Demand (%)—Continuously updated indication, even when failed, of the analog input position demand signal in percentage of the user calibrated range.
Actual Current (A)—Indication of the actual current, in amps, from the driver to the actuator. Position Demand Error (%)—Indication of the difference between the demand position and the actual position in percentage of the user calibrated range. This error is filtered based on the internal model to prevent inadvertent alarm indications (see position error alarm). Primary Demand (%)—Indication of the primary position demand signal, based on unit configuration,810-017038-002 in percentage of the user calibrated range. If the primary demand signal is failed, this parameter stops updating. Backup Demand (%)—Indication of the backup position demand signal, based on unit configuration, in percentage of the user calibrated range. If the backup demand signal is failed, this parameter stops updating.810-017038-002 Primary Control–Control Indication—True if the primary demand is the selected demand signal810-017038-002 . Primary Fault—Indication of the primary demand signal status. True indicates a failed value. This indication does not include a tracking error.
This command can be toggled between true and false. When toggled to true, the unit remains in a shutdown state until this parameter is set back to false or the power is cycled on the ProAct.810-017038-002 Status–Alarm—General indication that an alarm condition exists, refer to the Status Error—Alarms tab sheet for the specific alarm condition. Status–Shutdown—General indication that a Shutdown condition exists, refer to the Status Error—Shutdowns tab sheet for the specific condition.810-017038-002 Status–Low Pwr Stdby—General indication that the unit is in Low Power Standby Mode, refer to the Status Error—Shutdowns tab sheet for the specific condition. Service: Position Control The Position Control tab sheet contains position control information. Position Demand (%)—Indication of the actual position demand signal, based on unit configuration, in percentage of the user calibrated range. Actual Posn (%)—Indication of the actual driver shaft output position, in percentage of the user calibrated range.810-017038-002 Actual Posn (deg)—Indication of the actual driver shaft output position, in degrees rotation, relative to absolute shaft position. For models I through IV,810-017038-002 full counterclockwise is zero degrees and full clockwise is 75 degrees
